For Sunon 12V/24V 3D Printer Magnetic Suspension Bearing 5010 50mm Cooling Fan
MF50101V2-E01C-A99
Fan specification: 50x50x10
Voltage: 12V (voltage operation range: 8.5-13.5v)
Power: 0.45w
Current: 0.037amb (± 10%)
Air volume: 7.8cfm (cubic foot)
Speed: 4600rpm
Wind pressure: 0.07inch-h2o
Noise value: 21.4dba
Temperature range: - 10.. 70 ° C (optimum temperature range)
Outgoing way: lead (two-wire standard is red positive and black negative, special customized three-wire fan is red black positive and negative unchanged yellow line is special signal line) enclosure)
Fan material: 94vo flame retardant PBT plastic injection
Bearing structure: Maglev bearing (use the attraction between the magnetic guide element and the magnet to attract the whole fan blade rotor, so that the whole rotor fan blade can achieve the purpose of axis suspension between the bearings and hanging in the air after running)
KDE2405PFV1
kde1205pfv2.11.ms.a.gn
Fan specification: 50x50x10
Voltage: 12V (voltage operation range: 8.5-13.5v)
Power: 0.45w
Current: 0.037amb (± 10%)
Air volume: 7.8cfm (cubic foot)
Speed: 4600rpm
Wind pressure: 0.07inch-h2o
Noise value: 21.4dba
Temperature range: - 10.. 70 ° C (optimum temperature range)
Outgoing way: lead (two-wire standard is red positive and black negative, special customized three-wire fan is red black positive and negative unchanged yellow line is special signal line) enclosure)
Fan material: 94vo flame retardant PBT plastic injection
Bearing structure: Maglev bearing (use the attraction between the magnetic guide element and the magnet to attract the whole fan blade rotor, so that the whole rotor fan blade can achieve the purpose of axis suspension between the bearings and hanging in the air after running)
