| Oprating Temp. | -20°C to 70°C* | O-20°C to 70°C* | -20°C to 70°C* | -20°C to 70°C* | -20°C to 70°C* |
| Oprating Humidity. | -20°C to 60°C Less than 90%RH* | -20°C to 60°C Less than 90%RH* | -20°C to 60°C Less than 90%RH* | -20°C to 60°C Less than 90%RH* | Less than 90%RH* |
| Exceeding 60°C to 133.8g/m3* | Exceeding 60°C to 133.8g/m3* | Exceeding 60°C to 133.8g/m3* | Exceeding 60°C to 133.8g/m3* |
| Storage Temp. | -40°C to 80°C* | -40°C to 80°C* | -40°C to 80°C* | -40°C to 80°C* | -40°C to 80°C* |
| Storage Humidity. | -40°C to 60°C Less than 95%RH* | -40°C to 60°C Less than 95%RH* | -40°C to 60°C Less than 95%RH* | -40°C to 60°C Less than 95%RH* | Less than 95%RH* |
| Exceeding 60°C to 142.9g/m3* | Exceeding 60°C to 142.9g/m3* | Exceeding 60°C to 142.9g/m3* | Exceeding 60°C to 142.9g/m3* |
| Activation Force. | 0.05N to 0.8N | 0.05N to 0.8N | 0.05N to 0.8N | N/A | 0.5N +/- 0.3N |
| Oprating Life. | Over 10 million touches | Over 35 million touches | Over 10 million touches | Over 50 million touches | Over 1 million touches |
| Light Transmittance. | 80% (Typical) | 80% (Typical) | 76% (Typical) | 83% (Typical) | 76% / 78% (typical) |
| Surface Hardness. | 2H (JIS) | 2H (JIS) | 3H (JIS) | 6H (JIS) | 2H |
| Max Voltage. | DC6V | DC6V | DC5V | 6V | DC6V |
| Max Current. | 100mA(LR/UD) | 200mA(LR/UD) | Top 100mA/ Bottom 100mA | 200mA | 0.5mA |
| 0.5mA(XY) | 0.5mA(XY) | Between Top and Bottom 0.5mA |
| Terminal Resistance. | Less than 1kohm | Less than 200ohm | Less than 1kohm | N/A | Less than 30kohm |
| Linearity. | +/- 1% (typical) | Under 2% | Under 2% | Less than | N/A |
